Waterproof industrial IP65
momentary / latching-cabinet latch
The shell material:stainless steel
LED lights are available in red, green, blue, yellow, and white for selection
The voltage of the lamp includes: 1.8V,3V,5V,6V,12V,24V,36V,48V,110V,220V.
| Name | Specifications | Model | Notes |
| Φ 25 Flat momentary metal button | 5A current high Pin terminal | GQ25BF- 11/S | |
| Φ 25 High momentary metal button | 5A current high Pin terminal | GQ25BH- 11/S | |
| Φ 25 Flat maintained metal button | 5A current high Pin terminal | GQ25BF- 11Z/S | |
| Φ 25 High maintained metal button | 5A current high Pin terminal | GQ25BH- 11Z/S | |
| Φ 25 Flat ring lamp momentary metal button | 5A current high Pin terminal | GQ25BF- 11E/S | |
| Φ 25 High ring lamp momentary metal button | 5A current high Pin terminal | GQ25BH- 11E/S | |
| Φ 25 Flat ring lamp maintained metal button | 5A current high Pin terminal | GQ25BF- 11EZ/S | |
| Φ 25 High ring lamp maintained metal button | 5A current high Pin terminal | GQ25BH- 11EZ/S | |
| Φ 25 Flat ring lamp momentary metal button with luminous power logo | 5A current high Pin terminal | GQ25BF- 11EP/S | |
| Φ 25 Flat ring lamp maintained metal button with luminous power logo | 5A current high Pin terminal | GQ25BF- 11EZP/S | |
| GQ25B customizable 2NO2NC | increase 1NO1NC | The model has changed from 11 to 22 | |
| GQ25B Socket | GQ25B series,GQ30B series | GQ25BSocket(2wires) | Customizable wires length |
| GQ25B Socket | GQ25B series,GQ30B series | GQ25BSocket(4wires) | |
| GQ25B Socket | GQ25B series,GQ30B series | GQ25BSocket(6wires) | |
| GQ25B Socket | GQ25B series,GQ30B series | GQ25BSocket(8wires) | |
| GQ25B Socket | GQ25B series,GQ30B series | GQ25BSocket(10wires) |
Notes:
1. “/N”represents brass chrome plated housing， “/S”represents stainless steel housing.
2. Customizable color plated aluminum alloy shell，Please consult for specific prices.(Change the model suffix to“/A”)
3. GQ25、GQ30 defaults to stainless steel casing，If you need a large amount of brass chrome plated shell, you can consult for customization.
4. Packaging quantity：GQ6 is 50pcs in a box,GQ8 is 100pcs in a box,GQ10/GQ12 is 50pcs in a box,GQ16/GQ19 is 25pcs in a box,GQ22/GQ25/GQ30 is 10pcs in a box.
